Xaiv Thiab Qhov Chaw Tshuab Ib Tus Neeg Ua Haujlwm BGA SMT Qhov Chaw Tshuab Nrog Plaub Lub Taub Hau Thiab 44 Feeders

SMT tuaj tos thiab qhov chaw tshuab 7000pcs / h hwt444f Kev kub ceev ntse ntse ruaj khov siab peb hnub xa cov thawv ntoo

Xa kev nug

Khoom Taw qhia

Dab tsi ntawm cov neeg siv khoom tsim nyog rau kev yuav lub tshuab patch?

Patch machines feem ntau yog siv nyob rau hauv kev lag luam hluav taws xob, qhov chaw uas lawv yog lub luag hauj lwm rau lub systematic installation ntawm nto-mounted pab kiag li lawm mus rau cov luam Circuit Court boards. Cov neeg siv khoom zoo tshaj plaws rau cov tshuab patch yog cov uas koom nrog hauv kev tsim cov khoom siv hluav taws xob. Qee cov neeg siv khoom tshwj xeeb uas yuav tau txais txiaj ntsig los ntawm kev yuav cov tshuab patch suav nrog: 1. Cov kev pabcuam hluav taws xob tsim hluav taws xob (EMS) cov tuam txhab EMS cov tuam txhab cog lus nrog lwm cov lag luam los sib sau cov khoom siv hluav taws xob, thiab cov tshuab patch yog cov cuab yeej tseem ceeb hauv cov txheej txheem no. 2. Consumer electronics manufacturers Cov tuam txhab uas tsim cov khoom siv hluav taws xob rau cov neeg siv khoom, xws li smartphones, ntsiav tshuaj, thiab laptops, yuav tsum tau siv lub tshuab patch rau nruab chips thiab lwm yam khoom siv rau hauv Circuit Court boards. 3. Automotive electronics manufacturers Cov tuam txhab tsheb cia siab rau cov khoom siv hluav taws xob los txhawb lawv cov tsheb, thiab cov tshuab patch yog cov cuab yeej tseem ceeb hauv kev tsim cov khoom siv hluav taws xob rau cov tsheb. 4. Aerospace thiab tiv thaiv cov neeg cog lus Aerospace thiab tiv thaiv cov neeg cog lus nquag siv cov khoom siv hluav taws xob siab heev hauv lawv cov khoom, thiab cov tshuab patch yog cov cuab yeej tseem ceeb rau kev tso npe ntawm cov khoom siv saum npoo av. Hauv kev xaus, txhua lub lag luam koom nrog hauv kev tsim cov khoom siv hluav taws xob tuaj yeem tau txais txiaj ntsig los ntawm kev yuav cov tshuab patch. Cov tshuab no muaj txiaj ntsig tshwj xeeb rau kev sib dhos ceev thiab ua haujlwm ntawm cov khoom siv saum npoo av.

Qhov no yog cov lus teb rau cov neeg siv khoom zoo li cas rau kev yuav khoom lub tshuab patch lo lus nug. Ua tsaug rau koj cov xim rau Beijing Huawei Guochuang Electronic Technology Co., LTD., peb yog cov khoom lag luam zoo SMT, tuaj yeem lees txais OEM, ODM, cov chaw tsim khoom txhim khu kev qha, peb tab tom nrhiav rau tus neeg sawv cev thoob ntiaj teb, peb cov ntaub ntawv tiv toj: 15010550359 zhai 15931673319 liu.

banner

10-1


Number of Placement Heads	4 (siab precision)
Number of IC Tais	48
Tus naj npawb ntawm Feeders	50/44 (xws li 8mm feeder)
Positioning raug	0.01 hli
Rov qab Mounting raug	0.05 hli
Mounting ceev ntau yam tsis kam	5000-8000Pcs/h capacitance Cheebtsam
Siv tau Cov Cheebtsam	resistor, capacitor, nti, teeb hlaws 0201-30 * 30mm thiab lwm yam.
Txhawb Qhov Siab Tshaj Plaws ntawm PCB	50 * 50mm - (50F) 350 * 190mm / (44F) 350 * 260mm
Feeders	hluav taws xob feeder, pneumatic feeder, vibrating feeder, IC tais thiab lwm yam.
Cov cuab yeej paub	cim lub koob yees duab x1, lub koob yees duab ceev ceev x4, lub koob yees duab siab x1
Qhov siab tshaj plaws ntawm cov khoom siv	Tsawg dua los yog sib npaug li 7 hli
PCB Convey Hom	Peb-theem nkag, tsis siv neeg txuas ntawm sab laug mus rau sab xis, tsis siv neeg PCB tso
Mark Positioning	manual / automatic
Txoj kev Programming	tsis siv neeg programming tom qab manually importing cov ntaub ntawv ntawm PCB coordinates
Tswj System	HuaweiGuochuang tswj qhov system
Cov kauj ruam siab kawg ntawm XY Axis	629mm * 679 hli
Cov kab ntawm XY Axis	linear motion guide plus Screw driver
Motion hom ntawm XY Axis	ntse txuas ntawm acceleration thiab deceleration ntawm nkhaus thiab kab, integrated linear interpolation algorithm.
Tswj Computer	muaj kev tswj hwm lub computer nrog Intel cov txheej txheem ua haujlwm siab
Kho Txoj Kev Ntawm Txoj Kev	hluav taws xob
Ntau yam ntawm Nozzle Buffer	4.5mm ib
Qhov siab kawg theem ntawm Z axis	20 hli
Ntau yam ntawm lub kaum sab xis rau Cheebtsam	± 180 degree
Lub cev muaj zog	AC Servo Tsav Series
Tus tsav tsheb	high-speed DSP tsav tsheb
Huab cua yuav tsum tau	roj lim dej, Ntau dua lossis sib npaug li 50L, plua plav lim thiab cua siab stabilizer thiab lwm yam.
Nqus khoom ntawm Nozzle	Lub tshuab nqus tsev vacuum integrating lub tshuab nqus tsev tawg ua haujlwm siab
Ntau yam ntawm Cua Supply Pressure	0 5-0.7Mpa
OS	Kev tshawb nrhiav ywj pheej thiab kev txhim kho SMT ntse OS raws li Windows
PCB xav tau	3-5mm txheej txheem ntug hauv hom tsis siv neeg
Vision Display	17-inch industrial tswj zaub
Kab	flexible cable (10 lab lub sij hawm)
Fais fab mov	220V 50/60Hz
Lub zog nruab nrab	600W
Tshuab Dimensions	rooj tshuab 1140 * 900 * 900mm ntsug tshuab 900 * 1140 * 1340mm
Qhov hnyav	(lub rooj tshuab) 210kg ( ntsug tshuab) 280kg
